Daitsu FMCD*ECM series - Wall Pad Operation Guidelines

Page 54 of 62
SK2014‐SON‐002‐TechMnl‐FMCD‐003

D.2.2. WallPadOperationGuidelines

a) Clockdisplayandsetting
SystemhasanaccurateinternalrealtimeclockusedfortimeindicationandtimerON/OFFfunction.Clockdisplayarea
indicatesinternaltimeclockwhichcanbesetbythe
TIM
E
or
TIME
button.


b) Daydisplayandsetting
ThewallpadhasadaydisplayfunctionwhichisusedfordayindicationandtimerON/OFFfunction.Daydisplayicon
indicatescurrentday.Press
D
A
Y
buttontosetday.


c) TimerON/OFFsetting
IfthemasterunitisinglobalcontrolmodeandtheON/OFFtimersettingisselected,the masterunitwillcommand
the whole network to be on or off. Otherwise the ON/OFF timer affects the local unit only. The system supports
individualON/OFFtimersettingsforeachdayoftheweek.


 Press
TIMER
button once, and
O
N
symbol blinking indicates ON timer programming mode. The day
displayareaindicateswhich daythe timerisbeing set for. Ifthereis nopresetONtimer, the timerdisplay
areashows
,otherwisethe previoussetting will beshown. Press
TIM
E
or
TIM
E
buttonto changethe
ON timer setting. Press
CANCEL
key to cancel the current ON timer setting and the timer display area will
show
.Press
D
A
Y
buttontochangethedaytheONtimeristobeprogrammedfor.
 Press
TIMER
button again, and
OFF
symbol blinking indicates OFF timer programming mode. The
settingmethodisthesameastheONtimersettingabove.
 Press
TIMER
buttonagain,toexittheON/OFFtimersettingfunction.
 Should there be any ON or OFF timer settings programmed,
will light up. Should there be any
unexecutedONorOFFtimersettingsforthecurrentday,itscorresponding
O
N
or
OFF
iconwilllightup.
 Holddown
CANCEL
buttonfor3secondstocancelalltimersettings.


d) Timersetbymasterunitisasfollows:
 Press
NET
buttontoenterintonetworkingcontrolmode.Unitareablinkingindicatestheslaveunitunder
control.Press
TIME
or
TIM
E
toselectthedesiredslaveunit.Unitsthatareoffwillbeskippedautomatically.
 Press
TIMER
button once to enter into ON timer programming mode. Press
D
A
Y
button to select the
requireddayoftheweek.Masterunitwillthenretrievethesettingfromtheselectedslaveunitandthetimer
displayareawillshow“rEAd”.TheONtimersettingwillbeshownuponreadingthedatasuccessfully.Press
TIM
E
or
TIM
E
buttontochangetheONtimersettingoftheslaveunit.
 Press
TIMER
button again to enter into OFF timer programming mode. Press
D
A
Y
button to select the
requireddayoftheweek.Masterunitwillthenretrievethesettingfromtheselectedslaveunitandtimerthe
