D.2.3. ECUnitRPMSetting

1)TurnOFFtheunit.
2)Openwallpad’sbackcover,wheretwoDIPswitchescanbeseen.
3)TurntheDIPswitch1to“ON”position.




4)WiredwallpadLCDwilldisplaythefollowing;


5)AfterselectingtheRPMsetting,turntheDIPswitch1tothe“OFF”position.Thewiredwallpaddisplaywillresumeitsnormal
appearance.

ThisisthemotorRPMsetting.
PressTEMP.+/‐buttontoincreasetheRPM
settingby10RPMstep.
Thisisthespeedlevelsetting.
d0meanslowspeed
d1meansmediumspeed
d2meanshighspeed
PressPARAMETER+/‐buttontoselectspeed
