Page 8 of 62
SK2014‐SON‐002‐TechMnl‐FMCD‐003
Productrange: FMCD‐ECMHydronicHighWallwithECMotor
FMCD‐[Size]‐V~‐ECM 18 20 24
UnitConfiguration
Configuration 2‐pipe
NumberOfFanBlowers Single
PowerSupply (V/Ph/Hz)
230/1/50
220/1/60
OperationControl
~S:CompletefunctiononboardPCBwithintegratedgroupcontrolfunctionality,incl.1
pcreturnairsensorand2pcstemperaturesensors.
~W:LimitedfunctiononboardPCBwithdrain‐pump,louverandzonecontrol
functionality,incl.1pccoiltemperaturesensor.
PerformanceData
Air
TotalAirFlow
H
m
3
/hr
788 980 1240
M 740 760 760
L 570 600 600
Cooling
CoolingCapacity
e
H
kW
3.74 4.81 5.38
M 3.28 3.9 3.9
L 2.68 3.35 3.35
SensibleCoolingCapacity
e
H 2.74 3.46 3.89
M 2.4 2.8 2.8
L 1.95 2.38 2.38
FCEER
e
Rating 183 171 165
Class B B B
Heating
HeatingCapacity
e
H
kW
4.87 6.10 6.85
M 4.2 4.92 4.92
L 3.45 4.19 4.19
Max.ElectricHeaterCapacity 1.5
FCCOP
e
Rating 238 216 209
Class B B B
Sound
SoundPressureLevel(Outlet)
dB(A)
46/40/34 40/35/30 45/35/30
SoundPowerLevel(Outlet)
e
57/52/45 52/46/41 56/46/41
Electrical
FanMotorPower
e
H
W
30 41 60
M 20 24 24
L 13 18 18
FanMotorApparentPower@H 83 80 120
FanMotorRunningCurrent@H A 0.272 0.348 0.52
Hydraulic
CoolingWaterFlowRate
H
L/h
641.91 825.55 923.38
M 562.96 669.37 669.37
L 459.98 574.97 574.97
CoolingPressureDrop
e
H
kPa
45 52.2 63.3
M 37 36.6 36.6
L 25.6 28.1 28.1
HeatingWaterFlowRate
@H/M/L
L/h
Sameas"CoolingWaterFlowRate"
HeatingPressureDrop
e
H
kPa
36.2 42.3 51.3
M 28.8 29.4 29.4
L 20.4 22.6 22.6
WaterContent L 0.192 0.252 0.252
Construction
andPackingData
Water
Connections
Type
Socket(ThreadedFemale)
In
mm[in]
12.70[1/2]
Out
CondensateDrainageConnection 16[0.63]
Dimensions
L
mm
876 1063
W 228 240
H 300 310
NetWeight Kg 14 16 16
1."e"referstotechnicalinformationlistedontheEuroventwebsite.Euroventtestingconditions:
a.Coolingmode(2‐pipe): b.Heatingmode(2‐pipe):
‐Returnairtemperature:27CDB/19CWB. ‐Returnairtemperature:20C.
‐Inlet/Outletwatertemperature:7C/12C. ‐Inletwatertemperature:50C.
‐Waterflow‐rate:sameas2‐pipecooling.
