SK2014‐SON‐002‐TechMnl‐FMCD‐003



3.3) Wireconnectioncheck

3.3.1) Afterthewireconnectioniscompleted,pleasecheckthatthewirecolourscorrespond.

3.3.2) Checkthewirecontactbyusingamultimeter.


3.3.3) Check1and2,3and4,5and6tobesuretheconnectionsarecorrect.

3.3.4)If
theresistancebetweentwowirecontactsistoohigh,pleasecheckandreconnectthewirecontacts.
1
st

contact
2
nd
contact
3
rd
contact
4
th
contact
5
th
contact
6
th

contact
Firstunit Middleunit Lastunit
