SK2014‐SON‐002‐TechMnl‐FMCD‐003

SW2Systemsetting
0 2‐pipessystem
1 4‐pipessystem

SW4 Preheatsetting
1 28°C
0 36°C

4. MotorizedFanSpeedSettingsforDifferentModels:
UnitModel
Speed(RPM)
S3 SW5 SW6
Low Medium High
FMCD‐04 500 600 700 0 0 0
FMCD‐06 600 700 930 0 1 0
FMCD‐12 600 700 930 0 0 1
FMCD‐15 700 800 1150 0 1 1
FMCD‐18 900 1100 1300 1 0 0
FMCD‐20 800 900 1100 1 1 0
FMCD‐24 900 1200 1350 1 0 1
DefaultRPM 700 800 1100 1 1 1

5. Modeconfiguration:
DIPA‐S1 Model
SW7 SW8 Modelsetting
0 0 Cool‐Heat
0 1 Cool‐Heat+boosterheater
1 0 Coolingonly
1 1 Cool+primaryheater

6. UnitON/OFF

Thereare3waystoturnthesystemonoroff:
a) BytheON/OFFbuttononthehandsetorwiredwallpad.
b) Bytheprogrammabletimeronthehandsetorwiredwallpad.
c) Bythemanualcontrolbuttonontheairconditioner.

7.
Auto‐Restart
Thesystemusesanon‐volatilememorytosavethepresentoperationparameterswhensystemisturnedofforin
caseofsystemfailureorcessationofpowersupply.
Therestoredparameterdata‐setdependsonthetypeofuserinterface.
a)Handsetonlyuserinterface:
Whenthepower
onsignalis receivedbytheairconditionerandnowiredwall‐padisinstalled,theMode,
FanSpeed,Settemperatureand Louver/Swingsetting willbe the sameasthe handsetsetting beforethe
lastpoweroff.
b)Wall‐padonlyORwall‐padandhandsetuserinterface:
Whenthe
poweronsignalisreceivedbytheairconditionerandawiredwall‐padisinstalled,theMode,Fan
Speed,Settemperature,Louver/SwingsettingandTimerON/OFFweeklyprogramwillbethesameasthe
wallpadsettingbeforethelastpoweroff.
