Pr.96 Count Down Completion Settings
Factory Setting d00
Units None
Settings d00 ~ d999
This parameter defines the terminal count value for the internal counter. The counter can
be incremented by a low-to-high transition on a selected Multi-Function Input Terminal:
M1 or M2. Upon completion of the count, if Pr.45 is programmed to d13, the Multi-
Function Output Terminal (MO1) will be closed. If Pr.46 is programmed to d13, the Multi-
Function Relay Contact RA, RB, RC will be closed.
Pr.97 Preset Count Down Completion Settings
Factory Setting d00
Units None
Settings d00 ~ d999
This parameter sets a preliminary count value for the internal counter. The counter can
be incremented by a low-to-high transition on one of the programmed Multi-Function
Input Terminals: M1 or M2. The count starts at c01. When it reaches the preliminary
count value and the selected Multi-Function Output Terminal will be closed (Pr.45 = d14).
Preliminary Count can be used to initiate an external event before the "terminal count" is
reached. (Se Pr.38, 39, 40, 41, 42, 45, 46 for further details).
Pr.98 ~ Pr.99 Reserved
Pr.100 Software Version
Factory Setting d###
Units None
Settings None
This parameter shows the software version of the AC motor drive, and is read-only.
