VLT
®
MICRO
Chapter 5
Summary of Parameters
This chapter summarizes all 10 of the parameter groups. For complete descriptions of
individual parameters refer to Chapter 4.
No. Parameter Function Parameter Factory
Name Explanation Value Setting
00 Master Speed Master frequency d00:Master frequency input d00
Frequency source select determined by the digital
Setting control panel
d01:Master frequency input
determined by the analog
signal (DC 0 to +10 V)
d02:Master frequency input
determined by the analog
signal (DC 4 to 20 mA)
01 Operation Operation d00:Operating instructions d00
Command command determined by the digital
Source source select control panel
d01:Operating instructions
determined by the external
terminal connections,
keypad STOP key effective
d02:Operating instructions
determined by the external
terminal connections, keypad
STOP key not effective
02 Motor stop Motor stop d00:RAMP stop d00
method method select d01:Coasting to stop
03 V/F Curve Max output freq. d50.0 - d400. Hz d60.0
04 Setting Max voltage freq. d10.0 - d400. Hz d60.0
05 (13 & 14) Max output volt d2.0 - d255.0 V d220.
06 Mid-point freq. d0.1 - d400. Hz d1.50
07 Mid-point volt d002.0 - d255. V d12.0
08 Min output freq. d0.1 - d20.0 Hz d1.50
09 Min output volt d2.0 - d50.0 V d12.0
10 Accel/Decel Acceleration time 1 d0.1 - d600. sec d10.0
11 Time Setting Deceleration time 1 d0.1 - d600. sec d10.0
12 Acceleration time 2 d0.1 - d600. sec d10.0
62
