Pr.40 Multi-Function Input Terminals (M3)
Factory Setting d06
Units None
Settings d03 - d20
Pr.41 Multi-Function Input Terminals (M4)
Factory Setting d07
Units None
Settings d03 - d20
Pr.42 Multi-Function Input Terminals (M5)
Factory Setting d08
Units None
Settings d03 - d20
Parameter - Function List:
Value Function Value Function
d00 M0: Fwd./Stop, M1: Rev./Stop d11 1st-2nd Accel./Decel. Time Select
d01 M0: Run/Stop, M1: Fwd./Rev. d12 External Base Block
(Normally Closed)
d02 3-Wire Operation Control Mode d13 External Base Block (Normally Open)
d03 External Fault (Normally Open) d14 Increase Output Frequency Control
d04 External Fault (Normally Closed) d15 Decrease Output Frequency Control
d05 External Reset d16 Run PLC Program
d06 Multi-Step Speed Control 1 d17 Pause PLC Program
d07 Multi-Step Speed Control 2 d18 Counter Trigger
d08 Multi-Step Speed Control 3 d19 Counter Reset
d09 Jog Frequency d20 No Operation
d10 Accel./Decel. Speed Inhibit Control
33
