Danfoss 176F7302

VLT
®
MICRO
1: Mounting screw holes
2: Nameplate label
3: Bottom cover
4: Digital keypad
5: Upper cover
6: Ventilation hole
7: Input terminals
8: External input/output
terminals
9: B1, B2 External brake
resistor terminals
10: U, V, W Output terminals
7
7
8
9
10
U V W B1 B2
R S T
5
4
3
6
1
2
