FC 300 Instruction Manual
How to Program
" 14-** Special functions
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
14-0* Inverter switching
14-00 Switching Pattern [1] SFAVM All set-ups FALSE - Uint8
14-01 Switching Frequency [5] 5.0 kHz A ll set-ups FALSE - Uint8
14-03 Overmodulation [0] Off All set-ups FALSE - Uint8
14-04 PWM random [0] Off All set-ups FALSE - Uint8
14-1* Electrical power On/Off
14-10 Electrical failure [0] No function All set-ups FALSE - Uint8
14-11 Electrical Voltage at Electrical Fault 342 V All set-ups TRUE 0 Uint16
14-12 Function at Electrical Imbalance [0] Trip All set-ups TRUE - Uint8
14-2* Trip reset
14-20 Reset mode [0] Manual reset All se t-ups TRUE - Uint8
14-21 Automatic restart time 10 s All set-ups TRUE 0 U int16
14-22 Operation mode [0] Normal operation All set-ups TRUE - Uint8
14-25 Trip delay at torque limit 60 s = Off All set-ups FALSE 0 Uint8
14-29 Service code 0 All set-ups FALSE 0 Int32
14-3* Current limit ctrl.
14-30 Current lim cont, Proportional Gain 100 % All set-ups FALSE 0 Uint16
14-31 Current lim contr, Integration Time 0.020 s All set-ups FALSE -3 Uint16
14-5* Environment
14-50 RFI 1 [1] On 1 set-up FALSE - Uint8
*
default setting ()display text []value for use in comm unication via serial comm unication port
49
MG.33.A
6.22 - VLT is a registered Danfoss trademark
