Danfoss FC 300 Instruction Manual

FC 300 Instruction Manual
How to Program
" 15-** Dr ive informati o n
Par.
No. #
Parameter description Default value 4-set-up Change during
operation
Conver-
sion index
Type
15-0* Operating Data
15-00 Operating hours 0 h All set-ups FALSE 74 Uint32
15-01 Running hours 0 h A ll set-ups FALSE 74 Uint32
15-02 kWh counter 0. kWh All set-ups FALSE 75 Uint32
15-03 Power up’s 0 All set-ups FALSE 0 Uint32
15-04 Over temp’s 0 All set-ups FALSE 0 Uint16
15-05 Over volt’s 0 All set-ups FALSE 0 Uint16
15-06 Reset of kWh counter [0] Do not reset All set-ups FALSE - Uint8
15-07 Reset running hours counter [0] Do not reset All set-ups FALSE - Uint8
15-2* Historic Log
15-20 Historic log: Event 0 All set-ups FALSE 0 Uint8
15-21 Historic log: Value 0 All set-ups FALSE 0 Uint32
15-22 Historic log: Time 0 ms All set-ups FALSE -3 Uint32
15-3* Fault Log
15-30 Fault log: Error code 0 All set-ups FALSE 0 Uint8
15-31 Fault log: Value 0 All set-ups FALSE 0 Int16
15-32 Fault log: Time 0 s All set-ups FALSE 0 Uint32
15-4* Drive identification
15-40 FC type 0 All set-ups FALSE 0 VisStr[6]
15-41 Power section 0 All set-ups FALSE 0 VisStr[20]
15-42 Voltage 0 All set-ups FALSE 0 VisStr[20]
15-43 Software version 0 All set-ups FALSE 0 VisStr[5]
15-44 Ordered typecode string 0 All set-ups FALSE 0 VisStr[40]
15-45 Actual typecode string 0 All set-ups FALSE 0 V isStr[40]
15-46 Drive ordering no 0 All set-ups FALSE 0 VisStr[8]
15-47 Power card ordering no 0 All set-ups FALSE 0 VisStr[8]
15-48 LCP Id no 0 All set-ups FALSE 0 VisStr[20]
15-49 SW id control card 0 All set-ups FALSE 0 VisStr[20]
15-50 SW id power c ard 0 All set-ups FALSE 0 VisStr[20]
15-51 Drive serial number 0 All set-ups FALSE 0 VisStr[10]
15-53 Power card serial number 0 All set-ups FALSE 0 VisStr[19]
15-6* Option ident
15-60 Option in slot A 0 All set-ups FALSE 0 VisStr[30]
15-61 Slot A option SWversion 0 All set-ups FALSE 0 VisStr[20]
15-62 Slot A ordering no 0 All s et-ups FALSE 0 VisStr[8]
15-63 Slot A option serial number 0 All set-ups FALSE 0 VisStr[10]
15-65 Option in slot B 0 All set-ups FALSE 0 VisStr[30]
15-66 Slot B option SWversion 0 All set-ups FALSE 0 VisStr[20]
15-67 Slot B ordering no 0 All set-ups FALSE 0 VisStr[8]
15-68 Slot B option serial number 0 All set-ups FALSE 0 VisStr[10]
15-70 Option in slot C 0 All set-ups FALSE 0 VisStr[30]
15-71 Slot C option SWversion 0 All set-ups FALSE 0 VisStr[20]
15-72 Slot C ordering no 0 All set-ups FALSE 0 VisStr[8]
15-73 Slot C option s erial number 0 All set-ups FALSE 0 VisStr[10]
15-75 Option in slot D 0 All set-ups FALSE 0 VisStr[30]
15-9* Parameter info
15-92 Defined parameters 0 All set-ups FALSE 0 Uint16
15-93 Modified parameters 0 All set-ups FALSE 0 Uint16
15-99 Parameter metadata 0 All set-ups FALSE 0 Uint16
*
default setting ()display text []value for use in comm unication via serial comm unication port
50
MG.33.A
6.22 - VLT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
