HPRV Port Relationship
The illustration below illustrates the relationship between the HPRVs and the ports controlled by those
valves.
HPRV port relationship
HPRV valve
Controls port B
HPRV valve
Controls port A
HPRV valve
Controls port D
HPRV valve
Controls port C
