Item Fastener Wrench size Torque
V020 Charge pressure adjusting screw 6 mm internal hex NA
V022 Charge pressure locking nut 19 mm hex 40 N•m [30 lbf•ft]
Plug Size and Torque Chart
Item O-ring plug Wrench size Torque
B015 7/16 - 20 3/16 internal hex 20 N•m [15 lbf•ft]
B020 (45/53) 1-1/16 - 12 9/16 internal hex 48 N•m [35 lbf•ft]
B020 (60/68) 1-3/8 - 12 5/8 internal hex 148 N•m [109 lbf•ft]
D065 7/16 - 20 3/16 internal hex 12 N•m [9 lbf•ft]
G250 9/16 - 18 1/4 internal hex
(hardened plug)
45 N•m [33 lbf•ft]
Service Manual
H1T 045/053, 060/068 Axial Piston Tandem Pumps
Torque Chart
©
Danfoss | September 2020 AX152886481761en-000405 | 77
