Control Cut-off Valve / Brake Valve Repair
Replace the control cut-off valve as a complete unit. Do not attempt to repair the internal components of
the valve.
Control cutoff valve (045/053)
E101 401E
G10
G20
G30
G10A
9 N•m
[7 lbf•ft]
46 N•m
[34 lbf•ft]
1
1
/
16
in
24 mm
S
e
r
v
i
c
e
M
a
n
u
a
l
H
1
T
0
4
5
/
0
5
3
,
0
6
0
/
0
6
8
A
x
i
a
l
P
i
s
t
o
n
T
a
n
d
e
m
P
u
m
p
s
Minor repair
©
Danfoss | September 2020
AX152886481761en-000405 | 73
72
74
