525-690 V, Enclosure Types D, E and F
Size/
Type
Buss-
mann
E1250
85
JFHR2
[A]
SIBA
E1802
76
JFHR2
Ferraz-
Shawmut
E76491
JFHR2
Internal
Option
Bussmann
P45K 170M
3013
125 20610
32.125
6.6URD30D08
A0125
170M3015
P55K 170M
3014
160 20610
32.16
6.6URD30D08
A0160
170M3015
P75K 170M
3015
200 20610
32.2
6.6URD30D08
A0200
170M3015
P90K 170M
3015
200 20610
32.2
6.6URD30D08
A0200
170M3015
P110 170M
3016
250 20610
32.25
6.6URD30D08
A0250
170M3018
P132 170M
3017
315 20610
32.315
6.6URD30D08
A0315
170M3018
P160 170M
3018
350 20610
32.35
6.6URD30D08
A0350
170M3018
P200 170M
4011
350 20610
32.35
6.6URD30D08
A0350
170M5011
P250 170M
4012
400 20610
32.4
6.6URD30D08
A0400
170M5011
P315 170M
4014
500 20610
32.5
6.6URD30D08
A0500
170M5011
P400 170M
5011
550 20620
32.55
6.6URD32D08
A550
170M5011
Table 4.18 Enclosure Types D, E and F 525-690 V
Size/
Type
Bussmann
PN*
Rating Ferraz Siba
P450 170M4017 700 A,
700 V
6.9URD31
D08A070
0
20 610 32.700
P500 170M4017 700 A,
700 V
6.9URD31
D08A070
0
20 610 32.700
P560 170M6013 900 A,
700 V
6.9URD33
D08A090
0
20 630 32.900
P630 170M6013 900 A,
700 V
6.9URD33
D08A090
0
20 630 32.900
Table 4.19 Enclosure Type E, 525-690 V
Size/
Type
Bussmann
PN*
Rating Siba
Internal
Bussmann
Option
P710 170M7081 1600 A,
700 V
20 695 32.1600 170M7082
P800 170M7081 1600 A,
700 V
20 695 32.1600 170M7082
P900 170M7081 1600 A,
700 V
20 695 32.1600 170M7082
P1M0 170M7081 1600 A,
700 V
20 695 32.1600 170M7082
P1M2 170M7082 2000 A,
700 V
20 695 32.2000 170M7082
P1M4 170M7083 2500 A,
700 V
20 695 32.2500 170M7083
Table 4.20 Enclosure Type Size F, Line Fuses, 525-690 V
Size/Type
Bussmann
PN*
Rating Siba
P710 170M8611 1100 A,
1000 V
20 781 32. 1000
P800 170M8611 1100 A,
1000 V
20 781 32. 1000
P900 170M8611 1100 A,
1000 V
20 781 32. 1000
P1M0 170M8611 1100 A,
1000 V
20 781 32. 1000
P1M2 170M8611 1100 A,
1000 V
20 781 32. 1000
P1M4 170M8611 1100 A,
1000 V
20 781 32.1000
Table 4.21 Enclosure Type F, Inverter Module DC Link Fuses,
525-690 V
*170M fuses from Bussmann shown use the -/80 visual indicator, -
TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size
and amperage may be substituted for external use.
Suitable for use on a circuit capable of delivering not more
than 100 000 rms symmetrical A, 500/600/690 V maximum
when protected by the above fuses.
Supplementary fuses
Enclosure Type
Bussmann PN* Rating
D, E and F KTK-4 4 A, 600 V
Table 4.22 SMPS Fuse
Electrical Installation
VLT HVAC Drive FC 102 Operating Instructions
MG11F402 - Rev. 2013-12-16 61
4 4
