MCT Set-up 10 Software
Setting parameters
Copy to and from frequency converters
Documentation and print out of parameter
settings incl. diagrams
Ext. user interface
Preventive Maintenance Schedule
Clock settings
Timed Action Programming
Smart Logic Controller Set-up
Table 5.1
Ordering number:
Order the CD containing MCT 10 Set-up Software using
code number 130B1000.
The software can be downloaded from the Danfoss
internet site www.Danfoss.com/BusinessAreas/DrivesSo-
lutions/Softwaredownload/DDPC+Software+Program.htm
5.3.3
Tips and Tricks
•
For most HVAC applications the Quick Menu,
Quick Set-up and Function Set-up provides the
simplest and quickest access to all the typical
parameters required
•
Whenever possible, performing an AMA, ensures
best shaft performance
•
Contrast of the display can be adjusted by
pressing [Status] and [
▲
] for darker display or by
pressing [Status] and [
▼
] for brighter display
•
Under [Quick Menu] and [Changes Made] all
parameters that have been changed from factory
settings are displayed
•
Press and hold [Main Menu] key for 3 seconds for
access to any parameter
•
For service purposes it is recommended to copy
all parameters to the LCP, see 0-50 LCP Copy for
further information
5.3.4
Quick Transfer of Parameter Settings
when Using GLCP
Once the set-up of a frequency converter is complete, it is
recommended to store (back up) the parameter settings in
the GLCP or on a PC via MCT 10 Set-up Software Tool.
WARNING
Stop the motor before performing any of these
operations.
Data storage in LCP
1.
Go to 0-50 LCP Copy.
2. Press [OK].
3.
Select [1] All to LCP.
4. Press [OK].
All parameter settings are now stored in the GLCP
indicated by the progress bar. When 100% is reached,
press [OK].
The GLCP can now be connected to another frequency
converter and the parameter settings copied to this
frequency converter.
Data transfer from LCP to Frequency converter
1.
Go to 0-50 LCP Copy.
2. Press [OK].
3.
Select [2] All from LCP.
4. Press [OK]
The parameter settings stored in the GLCP are now
transferred to the frequency converter indicated by the
progress bar. When 100% is reached, press [OK].
5.3.5
Initialisation to Default Settings
There are 2 ways to initialise the frequency converter to
default: Recommended initialisation and manual initiali-
sation.
Be aware that they have different impact according to the
below description.
Recommended initialisation (via 14-22 Operation Mode)
1.
Select 14-22 Operation Mode.
2. Press [OK].
3.
Select [2] Initialisation (for NLCP select “2”).
4. Press [OK].
5. Remove power to unit and wait for display to
turn off.
6. Reconnect power and the frequency converter is
reset. Note that first start-up takes a few more
seconds.
7. Press [Reset]
14-22 Operation Mode initialises all except:
14-50 RFI Filter
8-30 Protocol
8-31 Address
8-32 Baud Rate
8-35 Minimum Response Delay
8-36 Max Response Delay
8-37 Maximum Inter-Char Delay
15-00 Operating hours to 15-05 Over Volt's
How to Operate the Frequenc...
VLT HVAC Drive FC 102 Operating Instructions
78 MG11F402 - Rev. 2013-12-16
