Danfoss Metasys N2 Operating Instructions

Size/Type Bussmann PN* LittelFuse Rating
P110-P315,
380-480 V
KTK-4 4 A, 600 V
P45K-P500,
525-690 V
KTK-4 4 A, 600 V
P355-P1M0,
380-480 V
KLK-15 15A, 600 V
P560-P1M4,
525-690 V
KLK-15 15A, 600 V
Table 4.23 Fan Fuses
Size/Type [A]
Bussma
nn
PN*
Rating
[V]
Alternative Fuses
P500-
P1M0,
380-480 V
2.5-
4.0
LPJ-6 SP
or SPI
6 A,
600
Any listed Class J Dual
Element, Time Delay, 6A
P710-
P1M4,
525-690 V
LPJ-10
SP
or SPI
10 A,
600
Any listed Class J Dual
Element, Time Delay, 10
A
P500-
P1M0,
380-480 V
4.0-
6.3
LPJ-10
SP
or SPI
10 A,
600
Any listed Class J Dual
Element, Time Delay, 10
A
P710-
P1M4,
525-690 V
LPJ-15
SP
or SPI
15 A,
600
Any listed Class J Dual
Element, Time Delay, 15
A
P500-
P1M0,
380-480 V
6.3
-
10
LPJ-15
SP
or SPI
15 A,
600
Any listed Class J Dual
Element, Time Delay, 15
A
P710-
P1M4,
525-690 V
LPJ-20
SP
or SPI
20 A,
600
Any listed Class J Dual
Element, Time Delay, 20A
P500-
P1M0,
380-480 V
10
-
16
LPJ-25
SP
or SPI
25 A,
600
Any listed Class J Dual
Element, Time Delay, 25
A
P710-
P1M4,
525-690 V
LPJ-20
SP
or SPI
20 A,
600
Any listed Class J Dual
Element, Time Delay, 20
A
Table 4.24 Manual Motor Controller Fuses
Enclosure
Type
Bussmann PN* Rating
Alternative
Fuses
F LPJ-30 SP or
SPI
30 A, 600 V Any listed
Class J Dual
Element, Time
Delay, 30 A
Table 4.25 30 A Fuse Protected Terminal Fuse
Enclosure
Type
Bussmann PN* Rating
Alternative
Fuses
F LPJ-6 SP or SPI 6 A, 600 V Any listed
Class J Dual
Element, Time
Delay, 6 A
Table 4.26 Control Transformer Fuse
Enclosure Type Bussmann PN* Rating
F GMC-800MA 800 mA, 250 V
Table 4.27 NAMUR Fuse
Enclosure
Type
Bussmann PN* Rating
Alternative
Fuses
F LP-CC-6 6 A, 600 V Any listed
Class CC, 6 A
Table 4.28 Safety Relay Coil Fuse with PILS Relay
4.1.15
Mains Disconnectors
Enclosure
Type Power & Voltage Type
D1/D3
P110-P132 380-480 V &
P110-P160 525-690 V
ABB OETL-NF200A or
OT200U12-91
D2/D4
P160-P250 380-480 V &
P200-P400 525-690 V
ABB OETL-NF400A or
OT400U12-91
E1/E2
P315 380-480 V & P450-
P630 525-690 V ABB OT600U03
E1/E2 P355-P450 380-480 V ABB OT800U03
F3
P500 380-480 V & P710-
P800 525-690 V
Merlin Gerin
NPJF36000S12AAYP
F3
P560-P710 380-480 V &
P900 525-690 V
Merlin Gerin
NRK36000S20AAYP
F4
P800-P1M0 380-480 V &
P1M0-P1M4 525-690 V
Merlin Gerin
NRK36000S20AAYP
Table 4.29
4.1.16
F Enclosure Circuit Breakers
Enclosur
e Type Power & Voltage Type
F3
P500 380-480 V & P710-
P800 525-690 V
Merlin Gerin
NPJF36120U31AABSCYP
F3
P560-P710 380-480 V &
P900 525-690 V
Merlin Gerin
NRJF36200U31AABSCYP
F4
P800 380-480 V & P1M0-
P1M4 525-690 V
Merlin Gerin
NRJF36200U31AABSCYP
F4 P1M0 380-480 V
Merlin Gerin
NRJF36250U31AABSCYP
Table 4.30
Electrical Installation
VLT HVAC Drive FC 102 Operating Instructions
62 MG11F402 - Rev. 2013-12-16
