Danfoss Metasys N2 User Manual

e30bu188.12
U
W
V
-XD4.1
-XD11.1
-XDL.1
3
4
U
W
V
1
2
5
Illustration 44: Split Shipment Electrical Connections (E5h/E6h Sine-wave Cabinets)
1
Additional terminal connections
2
Thermal protection wiring harness to drive cabinet
3
DC-link harness to fan power supply in drive cabinet
4
Cabinet heater supply harness to drive cabinet
5
Motor cables (U/V/W) to motor terminals (U/V/W) in
drive cabinet
AQ262141314214en-000301 / 130R088078 | Danfoss A/S © 2021.11
Electrical Installation
VLT® HVAC Drive FC 102
Operating Guide
