APPLICATION GUIDELINES
FRCC.PC.007.B5.02
17
ELECTRICAL DATA, CONNECTIONS AND WIRING
The temperature inside the terminal box may not
exceed 70°C. Consequently, if the compressor is
installed in an enclosure, precautions must be
taken to avoid that the temperature around the
compressor and in the terminal box would rise
too much. The installation of ventilation on the
enclosure panels may be necessary. If not, the
electronic protection module may not operate
properly. Any compressor damage related to this
will not be covered by Danfoss warranty. In the
same manner, cables must be selected in a way
to insure that terminal box temperature does not
exceed 70°C.
Terminal box temperature
IP rating
The compressor terminal box according to IEC529 is IP54 for all models when correctly sized IP54 rated
cable glands are used.
First numeral, level of protection against contact and foreign objects•
5 - Dust protected
Second numeral, level of protection against water•
4 - Protection against water splashing
Three phase electrical
characteristics
Compressor model
LRA MCC
Max. operating
current
Winding resistance
AAAΩ
Motor voltage code 3
200-230V / 3ph / 60 Hz
SH090 203 43 38 0.39
SH105 267 46 45 0.27
SH120 267 61 48 0.27
SH140 304 64 56 0.24
SH161 315 69 64 0.22
SH184 351 75 71 0.22
SH180 320 78 71 0.19
SH240 485 105 103 0.12
SH300 560 132 125 0.10
SH380 680 150 147 0.08
Motor voltage code 4
380-400 V / 3ph / 50 Hz
SH090 98 20 19 1.47
SH105 142 23 22 1.05
SH120 142 29 24 1.05
SH140 147 30 28 0.92
SH161 158 33 31 0.83
SH184 197 38.6 36 0.83
SH180 180 38 36 0.76
SH240 215 51 49 0.55
SH300 260 65 62 0.43
SH380 320 79 72 0.36
Motor voltage
code 6
230 V / 3ph /
50 Hz
SH090 157 40 32 0.5
SH105 223 43 38 0.35
SH120 223 51 41 0.35
SH140 236 53 49 0.31
SH161 236 57 53 0.31
SH184 236 57 56 0.31
Motor voltage code 7
500 V / 3ph / 50 Hz
575 V / 3 ph / 60 Hz
SH090 84 18 14 2.34
SH105 103 22 17 1.57
SH120 103 24 19 1.57
SH140 122 26 22 1.38
SH161 136 29 24 1.32
SH184 135 35 28 1.32
SH180 135 30 28 1.20
SH240 175 41 38 0.88
SH300 210 53 48 0.67
SH380 235 60 55 0.56
Motor voltage code 9
380 V / 3ph / 60 Hz
SH090 124 26 23 1.05
SH105 160 30 26 0.72
SH120 160 35 29 0.72
SH140 168 37 33 0.62
SH161 177 41 37 0.57
SH184 239 51 44 0.57
SH180 210 46 41 0.52
SH240 260 60 58 0.36
SH300 310 85 72 0.29
SH380 360 90 85 0.24
