APPLICATION GUIDELINES
FRCC.PC.007.B5.02
9
SH 140 & 161 code 3 & SH184
D
IMENSIONS
9
Flexible grommet
Ø 243
Oil sight
glass
Ø 243
(1) 278
(2) 300
(1) 101
(2) 108
(1) 101
(2) 108
(1) 509
(2) 525
(1) 540
(2) 555
(1) 155
(2) 170
157
4 x holes
Ø19.05
230
230
190.5
190.5
173
(1) 154
(2) 159
200
30°
30°
Ø 22
Ø 35
60°
(1) SH140 & 161 code 3
(2) SH184
All dimensions in mm
Equalisation
line
15 mm
HM 8 bolt
Lock washer
Flat washer
Steel mounting
sleeve
Rubber grommet
Nut
