Danfoss Performer SH090 User Manual

APPLICATION GUIDELINES
6
FRCC.PC.007.B5.02
Performer® SH scroll compressors for R410A are
available as single compressors. The example
below presents the compressor nomenclature
which equals the technical reference as shown on
the compressor nameplate.
Code numbers for ordering are listed section
"Ordering information and packaging".
For tandem and trio assemblies, please refer
to the Performer® SH scroll compressor Parallel
Application Guidelines, FRCC.EC.008.
Nomenclature
C
OMPRESSOR MODEL DESIGNATION
Family, lubricant
& refrigerant
SH: Scroll, POE lubricant,
for R410A
Motor protection
L: Internal overload protector
A: Electronic, 24V AC
B: Electronic, SH180: 230V
SH240-300-380: 115/230V
C: Customized electrical box
D: Electronic SH180: 115 V
F: Electronic, 24V DC
Suction and discharge connections
A: Brazed connections
M: Rotolock connections
Family,
lubricant
& refrigerant
Nominal
capacity
Approvals Voltage Version Evolution
index
Evolution index
A~Z
A4SH A AB300
Motor voltage code
3: 200-230V/3~/60 Hz
4: 380-400V/3~/50 Hz - 460V/3~/60 Hz
6: 230V/3~/50 Hz
7: 500V/3~/50 Hz - 575V/3~/60 Hz
9: 380V/3~/60 Hz
UL index
Nominal capacity
in thousand Btu/h at 60 Hz, R410A,
ARI conditions
