Appendix A: Power Line Accessories Installation
1. Figure A-69 shows a schematic of the main input circuit and connections to the line
reactor. Use this schematic as a guide for choosing the location of the line reactor.
2. Feed the AC line cable through the opening in the side of the main supply panel.
3. Attach the AC line wires to the line reactor terminals as shown in Figure A-70.
4. Attach the ground cable to the mounting block on the panel wall. Ensure there is good
electrical/mechanical contact between the ground cable and the panel wall.
5. Secure the AC line cable to the main supply panel using approved methods (i.e., cable
gland)
1. Feed the AC line cable through the opening in the side of the main supply panel.
2. Attach the AC line wires to the line reactor output terminals as shown in .
3. If a harmonic lter is being installed, attach its AC line wires to the line reactor output
terminals.
4. Attach the ground wire to the mounting block on the panel wall. Ensure there is good
electrical/mechanical contact between the ground wire and the panel wall.
5. Secure the AC line cable to the main supply panel using approved methods (i.e. cable
gland).
6. See Section 4.6 “Power Wiring” for instructions on completing the AC input connection
to the compressor.
These instructions apply to the installation of the line reactor kit in a main supply panel. See
the Spare Parts Selection Guide for product specications.
A.1.1 AC Line Cable
Connection (From
External Disconnect)
A.1.2 AC Line Cable
Connection (to
Compressor Terminal)
A.1 Line Reactor
Installation Instructions
NOTE
The customer is responsible for supplying the mounting hardware for the line reactor.
