Page 34 of 108
M-AP-001-EN Rev. N
M-AP-001-EN Rev. N
General Specifications
Table 5-3 - Maximum
Pressure Ratio Limits
Compressor TG230 ST* TG230 MT* TG310 ST TG390 ST TG520 ST TT300 ST* TT300 MT* TT350 ST TT400 ST TT700 ST
Alarm 4 4 5.2 3.5 3.5 4 4 5.2 3.5 3.5
Trip 5.2 5.2 5.5 4 4 5.2 5.2 5.5 4 4
*The TG230/TT300 compressor allows for adjustment of this setting.
Compressors which are placed in Air-Cooled applications can have this value increased up to 4.8.
NOTE
Pressure ratio must be calculated using absolute pressures. Refer to the OEM Programming Guide to identify the specic register
associated with the Pressure Ratio Alarm Limit.
Beyond these control limits, the Maximum Design High-Side Pressure for the compressor is
shown in Table 5-4.
Table 5-2 - Discharge
Temperature Trip Settings
Unit Compressor TG230 ST TG230 MT TG310 ST TG390 ST TG520 ST TT300 ST TT300 MT TT350 ST TT400 ST TT700 ST
°F Trip 212 194 203 194 194 212 194 203 194 194
°C Trip 100 90 95 90 90 100 90 95 90 90
NOTE
While the values here are represented in Gauge Pressure, the values in the registers will be dened in Absolute Pressure. Refer
to the OEM Programming Guide to identify the specic registers associated with the Discharge Pressure Alarm and Discharge
Pressure Trip Limits.
The compressor will also adjust its operation if the pressure ratio exceeds the alarm limit.
The Pressure Ratio alarm limit is dened in Table 5-3.
5.3 Maximum Discharge
Temperature
The maximum temperature that the compressor can operate is regulated directly by the Trip
Limit.
The Maximum Discharge Temperature Limits are dened in Table 5-2.
Table 5-4 - Maximum
Allowable Pressure [PS]
Unit
ALL
MODELS
kPag 2070
psig 300
