Table 6-3 FLA and LRA Value Range
NOTE
Refer to the OEM Programming Guide to identify specific registers associated with the “3-Phase Over Current Alarm (FLA) and
3-Phase Over Current Fault (LRA).”
6.3 Disconnects
An input disconnect (for example, a switch or circuit breaker) must be installed in the line before the
compressor in accordance with applicable local, national, and international safety regulations (for
example, NEC/CEC). Size the disconnect according to the full-load current.
• • • CAUTION • • •
The full-load current rating is based on the installation of a line reactor in the power line. Refer to the Spare Parts Selection Guide
for specifications. Failure to use a line reactor will result in poor power factor and higher full-load current.
Refer to "Figure 20-9 Typical Electrical Connections" on page 106 for interconnection details.
Model Voltage
FLA LRA Default
Min Max* Min Max FLA LRA
TGS230 380V 40 106 44 117 40 44
TGS230 400V 40 106 44 117 40 44
TGS230 460V 40 99 44 110 40 44
TGS230 575V 40 79 44 88 40 44
TGS310 380V 50 150 55 165 50 55
TGS310 400V 50 150 55 165 50 55
TGS310 460V 50 135 55 145 50 55
TGS390 380V 50 123 55 137 50 55
TGS390 400V 50 123 55 137 50 55
TGS390 460V 50 108 55 120 50 55
TGS390 575V 50 86 55 96 50 55
TGS490 380V 50 210 55 231 50 55
TGS490 400V 50 210 55 231 50 55
TGS490 460V 50 180 55 198 50 55
TGS520 380V 50 149 55 165 50 55
TGS520 400V 50 142 55 158 50 55
TGS520 460V 50 123 55 137 50 55
TGH285 380V 50 150 55 165 50 55
TGH285 400V 50 150 55 165 50 55
TGH285 460V 50 131 55 145 50 55
TTS300 380V 40 145 44 160 40 44
TTS300 400V 40 145 44 160 40 44
TTS300 460V 40 135 44 150 40 44
TTS300 575V 40 110 44 121 40 44
TTS350 380V 50 210 55 231 50 55
TTS350 400V 50 210 55 231 50 55
TTS350 460V 50 180 55 198 50 55
TTS400 380V 60 170 66 187 60 66
TTS400 400V 60 170 66 187 60 66
TTS400 460V 60 150 66 165 60 66
TTS400 575V 60 120 66 132 60 66
TTS700 380V 60 206 66 227 60 66
TTS700 400V 60 196 66 216 60 66
TTS700 460V 60 170 66 187 60 66
TTH375 380V 50 210 55 231 50 55
TTH375 400V 50 210 55 231 50 55
TTH375 460V 50 180 55 198 50 55
