Danfoss VLT 3516 User Manual

VLT
®
Series 3500
16
inches (mm)
Drawing 1
Type Input Overall Dimensions Mounting Dimensions
VAC H W D a b c d
Chassis 230 30.71 (780) 29.92 (760)
Chassis 380 9.53 (242) 10.24 (260) 7.87 (200) 0.39 (10) 0.39 (10)
Chassis 460
NEMA 1 230 31.50 (800) 29.92 (760)
NEMA 1 380 9.53 (242) 10.24 (260) 7.87 (200) 1.18 (30) 0.39 (10)
NEMA 1 460
Drawing 2
Type Input Overall Dimensions Mounting Dimensions
VAC H W D a b c d
NEMA 12 230
NEMA 12 380 31.89 (810) 13.78 (350) 11.02 (280) 12.83 (326) 22.05 (560) 7.09 (180) 2.76 (70)
NEMA 12 460
VLT 3516 Dimensions
W
a
b
c
0.98
(25)
0.33
(8.5)
Ø0.57
(14.5)
D
H
d
Drawing 2
Drawing 1
W
a
b
D
H
d
c
0.33
(8.5)
0.39
(10)
26.77 (680)
25.98 (660)
25.20 (640)
25.20 (640)
