VLT
®
Series 3500
82
408 Terminal 45 Output (OUTPUT 45)
Value:
Control ready (CONTROL READY) [0]
Unit ready (UNIT READY) [1]
Ready - remote control (UNT RDY RCTL) [2]
Enabled (ENABLED noWR) [3]
Running (RUNNING) [4]
Running, no warning (RUNNING noWR) [5]
Running in range, no warning (RUNinRANGE) [6]
Speed = reference, no warning
(RUN@REF noWR) [7]
Alarm (ALARM) [8]
Alarm or warning (ALARM or WARN) [9]
Current limit (CURRENT LIMIT) [10]
Out of frequency range (OUT FREQ RGE) [11]
Warning of F low (LO FREQ. WARN) [12]
Warning of F high (HI FREQ. WARN) [13]
Out of current range (OUT CURR RGE) [14]
Warning of I low (LO CURR. WARN) [15]
Warning of I high (HI CURR. WARN) [16]
0 to 100 Hz 0 to 20 mA (100 Hz 0-20 mA) [17]
0 to 100 Hz 4 to 20 mA(100 Hz 4-20 mA) [18]
★ 0 to f
MAX
0 to 20 mA(Fmax 0-20 mA) [19]
✔ 0 to f
MAX
4 to 20 mA (Fmax 4-20 mA) [20]
REF
MIN
to REF
MAX
0 to 20 mA(REFmax 0-20 mA) [21]
REF
MIN
to REF
MAX
4 to 20 mA(REFmax 4-20 mA) [22]
FB
MIN
to FB
MAX
0 to 20 mA(FBmax 0-20 mA) [23]
FB
MIN
to FB
MAX
4 to 20 mA(FBmax 4-20 mA) [24]
0 to I
MAX
0 to 20 mA(CURmax 0-20 mA) [25]
0 to I
MAX
4 to 20 mA(CURmax 4-20 mA) [26]
0 to I
LIM
0 to 20 mA(CURlim 0-20 mA) [27]
0 to I
LIM
4 to 20 mA(CURlim 4-20 mA) [28]
0 to kW
MAX
0 to 20 mA(PWRlim 0-20 mA) [29]
0 to kW
MAX
4 to 20 mA(PWRlim 4-20 mA) [30]
Function:
See function under parameter 407.
Description of choice:
See description of choice under parameter 407.
409 Terminal 01 Relay Output (RELAY 01)
Value:
Control ready (CONTROL READY) [0]
Unit ready (UNIT READY) [1]
Ready - remote control (UNT RDY RCTL) [2]
✔ Enabled (ENABLED noWR) [3]
Running (RUNNING) [4]
Running, no warning (RUNNING noWR) [5]
Running in range, no warning (RUNinRANGE) [6]
Speed = reference, no warning (RUN@REF noWR) [7]
★ Alarm (ALARM) [8]
Alarm or warning (ALARM or WARN) [9]
Current limit (CURRENT LIMIT) [10]
Out of frequency range (OUT FREQ RGE) [11]
Warning of F low (LO FREQ. WARN) [12]
Warning of F high (HI FREQ. WARN) [13]
Out of current range (OUT CURR RGE) [14]
Warning of I low (LO CURR. WARN) [15]
Warning of I high (HI CURR. WARN) [16]
Motor thermal overload (MOT.THERM.WARN) [17]
Ready and no motor thermal overload
(READY+MOT.OK) [18]
Ready and remote control (RDY+MOT+REM) [19]
Ready and no over/undervoltage (RDY+DC V OK) [20]
Idle running current (NO LOAD CURR) [21]
Function:
Relay output 01 and relay output 04 can be used for indi-
cating status and warnings. The relay is activated when the
conditions for the different data values are fulfilled. Activa-
tion/deactivation of relay 01 can be delayed by parameters
316 and 317. When relay 01 is active, its contacts connect
terminal 01 to terminal 02. When it is not active, its contacts
connect terminal 01 to terminal 03.
Description of choice:
[0]-[16]: See explanations under parameter 407.
[17] The electronic motor thermal overload indicates
that the motor is overheated
[18] VLT is ready and the electronic motor thermal pro-
tection indicates that there is no motor thermal
overload.
[19] VLT is ready and is in remote control mode (Auto).
[20] VLT is ready and the DC bus voltage is OK.
[21] The output current from the drive is below the idle
running current set in parameter 232.
★ = ROM default setting. ✔ = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.
