Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
1-0* General Settings 1-00 Configuration Mode null All set-ups TRUE - Uint8 1-01 Motor Control Principle null All set-ups FALSE - Uint8
1-03 Torque Characteristics [3] Auto Energy Optim. VT All set-ups TRUE - Uint8
1-1* Motor Selection 1-10 Motor Construction [0] Asynchron All set-ups FALSE - Uint8 1-2* Motor Data 1-20 Motor Power [kW] ExpressionLimit All set-ups FALSE 1 Uint32 1-21 Motor Power [HP] ExpressionLimit All set-ups FALSE -2 Uint32
1-22 Motor Voltage ExpressionLimit All set-ups FALSE 0 Uint16
1-23 Motor Frequency ExpressionLimit All set-ups FALSE 0 Uint16
1-24 Motor Current ExpressionLimit All set-ups FALSE -2 Uint32
1-25 Motor Nominal Speed ExpressionLimit All set-ups FALSE 67 Uint16
1-28 Motor Rotation Check [0] Off All set-ups FALSE - Uint8
1-29 Automatic Motor Adaptation (AMA) [0] Off All set-ups FALSE - Uint8 1-3* Adv. Motor Data 1-30 Stator Resistance (Rs) ExpressionLimit All set-ups FALSE -4 Uint32 1-31 Rotor Resistance (Rr) ExpressionLimit All set-ups FALSE -4 Uint32 1-35 Main Reactance (Xh) ExpressionLimit All set-ups FALSE -4 Uint32
1-36 Iron Loss Resistance (Rfe) ExpressionLimit All set-ups FALSE -3 Uint32
1-39 Motor Poles ExpressionLimit All set-ups FALSE 0 Uint8
1-5* Load Indep. Setting
1-50 Motor Magnetisation at Zero Speed 100 % All set-ups TRUE 0 Uint16 1-51 Min Speed Normal Magnetising [RPM] ExpressionLimit All set-ups TRUE 67 Uint16 1-52 Min Speed Normal Magnetising [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
1-6* Load Depen. Setting
1-60 Low Speed Load Compensation 100 % All set-ups TRUE 0 Int16 1-61 High Speed Load Compensation 100 % All set-ups TRUE 0 Int16 1-62 Slip Compensation 0 % All set-ups TRUE 0 Int16
1-63 Slip Compensation Time Constant ExpressionLimit All set-ups TRUE -2 Uint16
1-64 Resonance Dampening 100 % All set-ups TRUE 0 Uint16
1-65 Resonance Dampening Time Constant 5 ms All set-ups TRUE -3 Uint8
1-7* Start Adjustments 1-71 Start Delay 0.0 s All set-ups TRUE -1 Uint16 1-73 Flying Start [0] Disabled All set-ups FALSE - Uint8
1-74 Start Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
1-75 Start Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
1-76
Start Current 0.00 A All set-ups TRUE -2 Uint32
1-8* Stop Adjustments 1-80 Function at Stop [0] Coast All set-ups TRUE - Uint8 1-81 Min Speed for Function at Stop [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
1-82 Min Speed for Function at Stop [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
1-86 Trip Speed Low [RPM] 0 RPM All set-ups TRUE 67 Uint16
1-87
Trip Speed Low [Hz] 0 Hz All set-ups TRUE -1 Uint16
1-9* Motor Temperature 1-90 Motor Thermal Protection [4] ETR trip 1 All set-ups TRUE - Uint8 1-91 Motor External Fan [0] No All set-ups TRUE - Uint16
1-93 Thermistor Source [0] None All set-ups TRUE - Uint8
8.3.3. Load/Motor 1-**
VLT
®
AQUA Drive
Operating Instructions
8. How to programme the frequency converter
MG.20.M5.02 - VLT
®
is a registered Danfoss trademark 111
8
