7.1.8. Read-out and Programming of Indexed Parameters
Parameters are indexed when placed in a rolling stack.
par. 15-30 Alarm
Log: Error Code
to par. 15-32 Alarm
Log: Time
contain a fault log which can be read out. Choose a parameter, press [OK], and use the
up/down navigation keys to scroll through the value log.
Use par. 3-10
Preset Reference
as another example:
Choose the parameter, press [OK], and use the up/down navigation keys keys to scroll through the indexed values. To change the parameter value,
select the indexed value and press [OK]. Change the value by using the up/down keys. Press [OK] to accept the new setting. Press [Cancel] to abort.
Press [Back] to leave the parameter.
7.1.9. Tips and tricks
* For the majority of water and wastewater applications the Quick Menu, Quick Setup and Function Setups provides the simplest
and quickest access to all the typical parameters required.
* Whenever possible, performing an AMA, will ensure best shaft performance
* Contrast of the display can be adjusted by pressing [Status] and [] for darker display or by pressing [Status] and [] for
brighter dispaly
* Under [Quick Menu] and [Changes Made] all parameters that have been changed from factory settings are displayed
* Press and hold [Main Menu] key for 3 seconds for access to any parameter
* For service purposes it is recommended to copy all parameters to the LCP, see par 0-50 for further information
Table 7.1: Tips and tricks
7.1.10. Quick Transfer of Parameter Settings when using GLCP
Once the set-up of a frequency converter is complete, it is recommended to store (backup) the parameter settings in the GLCPkeypad or on a PC via
MCT 10 Set-up Software Tool.
NB!
Stop the motor before performing any of these operations.
Data storage in LCP:
1. Go to par. 0-50 LCP
Copy
2. Press the [OK] key
3. Select “All to LCP”
4. Press the [OK] key
All parameter settings are now stored in the GLCP indicated by the progress bar. When 100% is reached, press [OK].
The GLCP can now be connected to another frequency converter and the parameter settings copied to this frequency converter.
Data transfer from LCP to Frequency converter:
1. Go to par. 0-50 LCP
Copy
2. Press the [OK] key
3. Select “All from LCP”
4. Press the [OK] key
The parameter settings stored in the GLCP are now transferred to the frequency converter indicated by the progress bar. When 100% is reached, press
[OK].
VLT
®
AQUA Drive
Operating Instructions
7. How to operate the frequency converter
MG.20.M5.02 - VLT
®
is a registered Danfoss trademark
59
7
