Danfoss VLT AQUA Drive FC 202 Operating Instructions

Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
8-0* General Settings 8-01 Control Site null All set-ups TRUE - Uint8 8-02 Control Source null All set-ups TRUE - Uint8
8-03 Control Timeout Time ExpressionLimit 1 set-up TRUE -1 Uint32
8-04 Control Timeout Function [0] Off 1 set-up TRUE - Uint8
8-05 End-of-Timeout Function [1] Resume set-up 1 set-up TRUE - Uint8
8-06 Reset Control Timeout [0] Do not reset All set-ups TRUE - Uint8
8-07 Diagnosis Trigger [0] Disable 2 set-ups TRUE - Uint8
8-1* Control Settings 8-10 Control Profile [0] FC profile All set-ups TRUE - Uint8 8-13 Configurable Status Word STW [1] Profile Default All set-ups TRUE - Uint8
8-14 Configurable Control Word CTW [1] Profile default All set-ups TRUE - Uint8
8-3* FC Port Settings 8-30 Protocol null 1 set-up TRUE - Uint8 8-31 Address ExpressionLimit 1 set-up TRUE 0 Uint8
8-32 Baud Rate null 1 set-up TRUE - Uint8
8-33 Parity / Stop Bits null 1 set-up TRUE - Uint8
8-35 Minimum Response Delay ExpressionLimit 1 set-up TRUE -3 Uint16
8-36 Max Response Delay ExpressionLimit 1 set-up TRUE -3 Uint16
8-37 Maximum Inter-Char Delay ExpressionLimit 1 set-up TRUE -5 Uint16
8-4* FC MC protocol set 8-40 Telegram Selection [1] Standard telegram 1 2 set-ups TRUE - Uint8 8-5* Digital/Bus 8-50 Coasting Select [3] Logic OR All set-ups TRUE - Uint8 8-52 DC Brake Select [3] Logic OR All set-ups TRUE - Uint8
8-53 Start Select [3] Logic OR All set-ups TRUE - Uint8
8-54 Reversing Select null All set-ups TRUE - Uint8
8-55 Set-up Select [3] Logic OR All set-ups TRUE - Uint8
8-56 Preset Reference Select [3] Logic OR All set-ups TRUE - Uint8
8-7* BACnet
8-70 BACnet Device Instance 1 N/A 1 set-up TRUE 0 Uint32
8-72 MS/TP Max Masters 127 N/A 1 set-up TRUE 0 Uint8
8-73 MS/TP Max Info Frames 1 N/A 1 set-up TRUE 0 Uint16
8-74 "I-Am" Service [0] Send at power-up 1 set-up TRUE - Uint8
8-75 Initialisation Password ExpressionLimit 1 set-up TRUE 0 VisStr[20]
8-8* FC Port Diagnostics
8-80 Bus Message Count 0 N/A All set-ups TRUE 0 Uint32
8-81 Bus Error Count 0 N/A All set-ups TRUE 0 Uint32
8-82 Slave Message Rcvd 0 N/A All set-ups TRUE 0 Uint32
8-83 Slave Error Count 0 N/A All set-ups TRUE 0 Uint32
8-9* Bus Jog / Feedback 8-90 Bus Jog 1 Speed 100 RPM All set-ups TRUE 67 Uint16 8-91 Bus Jog 2 Speed 200 RPM All set-ups TRUE 67 Uint16
8-94 Bus Feedback 1 0 N/A 1 set-up TRUE 0 N2
8-95 Bus Feedback 2 0 N/A 1 set-up TRUE 0 N2
8-96 Bus Feedback 3 0 N/A 1 set-up TRUE 0 N2
8.3.9. Comm. and Options 8-**
VLT
®
AQUA Drive
Operating Instructions
8. How to programme the frequency converter
MG.20.M5.02 - VLT
®
is a registered Danfoss trademark 117
8
