29-05 Filled Setpoint
Range: Function:
0 s* [0 – 999999,999 s] Specifies the Filled Set-point at which the Pipe Fill Function will be disabled and the PID controller
will take control. This function can be used both for horizontal and vertical pipe systems.
8.3. Parameter Options
8.3.1. Default settings
Changes during operation:
”TRUE” means that the parameter can be changed while the frequency converter is in operation and “FALSE” means that the frequency converter must
be stopped before a change can be made.
4-Set-up:
'All set-up': the parameter can be set individually in each of the four set-ups, i. e. one single parameter can have four different data values.
’1 set-up’: data value will be the same in all set-ups.
SR:
Size related
N/A:
No default value available.
Conversion index:
This number refers to a conversion figure used when writing or reading by means of a frequency converter.
Conv. index 100 67 6 5 4 3 2 1 0 -1 -2 -3 -4 -5 -6
Conv. factor 1 1/60 1000000 100000 10000 1000 100 10 1 0.1 0.01 0.001 0.0001 0.00001 0.000001
Data type Description Type
2 Integer 8 Int8
3 Integer 16 Int16
4 Integer 32 Int32
5 Unsigned 8 Uint8
6 Unsigned 16 Uint16
7 Unsigned 32 Uint32
9 Visible String VisStr
33 Normalized value 2 bytes N2
35 Bit sequence of 16 boolean variables V2
54 Time difference w/o date TimD
8. How to programme the frequency converter
VLT
®
AQUA Drive
Operating Instructions
108
MG.20.M5.02 - VLT
®
is a registered Danfoss trademark
8
