5-21 Terminal X46/3 Digital Input
Option: Function:
[0] * No operation This parameter is active when option moduleMCB 113 is installed in the frequency converter. Func-
tions are described under 5-1*
Digital Inputs
5-22 Terminal X46/5 Digital Input
Option: Function:
[0] * No operation This parameter is active when option moduleMCB 113 is installed in the frequency converter. Func-
tions are described under 5-1*
Digital Inputs
5-23 Terminal X46/7 Digital Input
Option: Function:
[0] * No operation This parameter is active when option moduleMCB 113 is installed in the frequency converter. Func-
tions are described under 5-1*
Digital Inputs
5-24 Terminal X46/9 Digital Input
Option: Function:
[0] * No operation This parameter is active when option module MCB 113 is installed in the frequency converter. Func-
tions are described under 5-1*
Digital Inputs
5-25 Terminal X46/11 Digital Input
Option: Function:
[0] * No operation This parameter is active when option moduleMCB 113 is installed in the frequency converter. Func-
tions are described under 5-1*
Digital Inputs
5-26 Terminal X46/13 Digital Input
Option: Function:
[0] * No operation This parameter is active when option module MCB 113 is installed in the frequency converter. Func-
tions are described under 5-1*
Digital Inputs
3.7.4 5-3* Digital Outputs
Parameters for configuring the output functions for the output terminals. The 2 solid-state digital outputs are common for terminals 27 and 29. Set the
I/O function for terminal 27 in par. 5-01
Terminal 27 Mode
, and set the I/O function for terminal 29 in par. 5-02
Terminal 29 Mode
. These parameters
cannot be adjusted while the motor is running.
[0] No operation
Default for all digital outputs and relay outputs
[1] Control ready The control card is ready. E.g.: Feedback from a drive where the control is supplied by an external
24 V (MCB107) and the main power to drive is not detected.
[2] Drive ready The frequency converter is ready for operation and applies a supply signal on the control board.
[3] Drive ready / remote control The frequency converter is ready for operation and is in Auto On mode.
[4] Enable / no warning Ready for operation. No start or stop command is been given (start/disable). No warnings are active.
[5] VLT running Motor is running and shaft torque present.
[6] Running / no warning Output speed is higher than the speed set in par. 1-81
Min Speed for Function at Stop [RPM]
. The
motor is running and there are no warnings.
[7] Run in range / no warning Motor is running within the programmed current and speed ranges set in par. 4-50
Warning Current
Low
to par. 4-53
Warning Speed High
. There are no warnings.
[8] Run on reference / no warning Motor runs at reference speed. No warnings.
[9] Alarm An alarm activates the output. There are no warnings.
[10] Alarm or warning An alarm or a warning activates the output.
[11] At torque limit The torque limit set in par. 4-16
Torque Limit Motor Mode
or par. 4-17 has been exceeded.
[12] Out of current range The motor current is outside the range set in par. 4-18
Current Limit
.
FC 300 Programming Guide 3 Parameter descriptions
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
99
