Danfoss VLT AutomationDrive FC 300 Programming Guide

4-50 Warning Current Low
Range: Function:
0.00 A* [Application dependant] Enter the I
LOW
value. When the motor current falls below this limit, the display reads Current Low .
The signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302
only) and on relay output 01 or 02 (FC 302 only). Refer to the drawing in this section.
4-51 Warning Current High
Range: Function:
Application
dependent*
[Application dependant] Enter the I
HIGH
value. When the motor current exceeds this limit, the display reads Current High .
The signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302
only) and on relay output 01 or 02 (FC 302 only). Refer to the drawing in this section.
4-52 Warning Speed Low
Range: Function:
0 RPM* [Application dependant] Enter the n
LOW
value. When the motor speed exceeds this limit, the display reads Speed Low . The
signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302 only)
and on relay output 01 or 02 (FC 302 only).
4-53 Warning Speed High
Range: Function:
Application
dependent*
[Application dependant] Enter the n
HIGH
value. When the motor speed exceeds this limit, the display reads Speed High . The
signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302 only)
and on relay output 01 or 02 (FC 302 only). Programme the upper signal limit of the motor speed,
n
HIGH
, within the normal working range of the frequency converter. Refer to the drawing in this
section.
4-54 Warning Reference Low
Range: Function:
-999999.99
9*
[Application dependant] Enter the lower reference limit. When the actual reference falls below this limit, the display indicates
Ref Low . The signal outputs can be programmed to produce a status signal on terminal 27 or 29
(FC 302 only) and on relay output 01 or 02 (FC 302 only).
4-55 Warning Reference High
Range: Function:
999999.999
*
[Application dependant] Enter the upper reference limit. When the actual reference exceeds this limit, the display reads Ref
High. The signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC
302 only) and on relay output 01 or 02 (FC 302 only).
4-56 Warning Feedback Low
Range: Function:
-999999.99
9 Referen-
ceFeedback-
Unit*
[Application dependant] Enter the lower feedback limit. When the feedback falls below this limit, the display reads Feedb
Low. The signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC
302 only) and on relay output 01 or 02 (FC 302 only).
4-57 Warning Feedback High
Range: Function:
999999.999
Reference-
FeedbackU-
nit*
[Application dependant] Enter the upper feedback limit. When the feedback exceeds this limit, the display reads Feedb High.
The signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302
only) and on relay output 01 or 02 (FC 302 only).
3 Parameter descriptions FC 300 Programming Guide
90 MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
3
