[63] Comparator 3 See par. group 13-1*. If Comparator 3 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
[64] Comparator 4 See par. group 13-1*. If Comparator 4 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
[65] Comparator 5 See par. group 13-1*. If Comparator 5 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
[70] Logic Rule 0 See par. group 13-4*. If Logic Rule 0 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
[71] Logic Rule 1 See par. group 13-4*. If Logic Rule 1 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
[72] Logic Rule 2 See par. group 13-4*. If Logic Rule 2 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
[73] Logic Rule 3 See par. group 13-4*. If Logic Rule 3 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
[74] Logic Rule 4 See par. group 13-4*. If Logic Rule 4 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
[75] Logic Rule 5 See par. group 13-4*. If Logic Rule 5 is evaluated as TRUE, the output will go high. Otherwise, it
will be low.
[80] SL Digital Output A See par. 13-52
SL Controller Action . The output will go high whenever the Smart Logic Action [38]
Set dig. out. A high is executed. The output will go low whenever the Smart Logic Action [32] Set
dig. out. A low is executed.
[81] SL Digital Output B See par. 13-52
SL Controller Action . The input will go high whenever the Smart Logic Action [39]
Set dig. out. A high is executed. The input will go low whenever the Smart Logic Action [33] Set
dig. out. A low
is executed.
[82] SL Digital Output C See par. 13-52
SL Controller Action . The input will go high whenever the Smart Logic Action [40]
Set dig. out. A high is executed. The input will go low whenever the Smart Logic Action [34] Set
dig. out. A low
is executed.
[83] SL Digital Output D See par. 13-52
SL Controller Action . The input will go high whenever the Smart Logic Action [41]
Set dig. out. A high is executed. The input will go low whenever the Smart Logic Action [35] Set
dig. out. A low
is executed.
[84] SL Digital Output E See par. 13-52
SL Controller Action . The input will go high whenever the Smart Logic Action [42]
Set dig. out. A high is executed. The input will go low whenever the Smart Logic Action [36] Set
dig. out. A low
is executed.
[85] SL Digital Output F See par. 13-52
SL Controller Action . The input will go high whenever the Smart Logic Action [43]
Set dig. out. A high is executed. The input will go low whenever the Smart Logic Action [37] Set
dig. out. A low
is executed.
[120] Local reference active Output is high when par. 3-13
Reference Site = [2] Local or when par. 3-13 Reference Site = [0]
Linked to hand auto at the same time as the LCP is in Hand on mode.
Reference site set in par. 3-13 Local reference
active [120]
Remote reference
active [121]
Reference site: Local par. 3-13 [2] 1 0
Reference site: Remote par. 3-13 [1] 0 1
Reference site: Linked to Hand/ Auto
Hand 1 0
Hand -> off 1 0
Auto -> off 0 0
Auto 0 1
[121] Remote reference active Output is high when par. 3-13 Reference Site = Remote [1] or Linked to hand/auto [0] while the
LCP is in [Auto on] mode. See above.
[122] No alarm Output is high when no alarm is present.
