[83] SL Digital Output D SL Controller Action. The input will go high whenever the Smart Logic Action [41] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [35] Set dig. out. A low is
executed.
[84] SL Digital Output E SL Controller Action. The input will go high whenever the Smart Logic Action [42] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [36] Set dig. out. A low is
executed.
[85] SL Digital Output F SL Controller Action. The input will go high whenever the Smart Logic Action [43] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [37] Set dig. out. A low is
executed
8-14 Configurable Control Word CTW
Option: Function:
Selection of control word bit 10 if it is active low or active high
[0] None
[1] * Profile default
[2] CTW Valid, active low
3.10.4 8-3* FC Port Settings
Parameters for configuring the FC Port.
8-30 Protocol
Option: Function:
[0] * FC
[1] FC MC Select the protocol for the FC (standard) port.
[2] * Modbus RTU
8-31 Address
Range: Function:
Application
dependent*
[Application dependant] Enter the address for the FC (standard) port.
Valid range: 1 - 126.
8-32 FC Port Baud Rate
Option: Function:
[0] 2400 Baud Baud rate selection for the FC (standard) port.
[1] 4800 Baud
[2] * 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
8-33 Parity / Stop Bits
Option: Function:
[0] * Even Parity, 1 Stop Bit
[1] Odd Parity, 1 Stop Bit
[2] No Parity, 1 Stop Bit
[3] No Parity, 2 Stop Bits
FC 300 Programming Guide 3 Parameter descriptions
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark 139
3
