Danfoss VLT AutomationDrive FC 300 Programming Guide

12-09 Physical Address
Range: Function:
[00:1B:08:00:00:00 – 00:1B:
08:FF:FF:FF]
Read only Displays the Physical (MAC) address of the option.
3.13.2 12-1* Ethernet Link Parameters
12-1* Ethernet Link Parameters
Option: Function:
Applies for whole parameter group.
[0] Port 1
[1] Port 2
12-10 Link Status
Option: Function:
Read only. Displays the link status of the Ethernet ports.
[0] No link
[1] Link
12-11 Link Duration
Option: Function:
Link Duration Port 1 (dd:hh:mm:ss) Read only. Displays the duration of the present link on each port in dd:hh:mm:ss.
12-12 Auto Negotiation
Option: Function:
Configures Auto Negotiation of Ethernet link parameters, for each port: ON or OFF.
[0] Off
Link Speed and Link Duplex can be configured in par. 12-13 and 12-14.
[1] On
12-13 Link Speed
Option: Function:
Forces the link speed for each port in 10 or 100 Mbps. If par. 12-12 is set to: ON, this parameter is
read only and displays the actual link speed. “None” is displayed if no link is present.
[0] * None
[1] 10 Mbps
[2] 100 Mbps
12-14 Link Duplex
Option: Function:
Forces the duplex for each port to Full or Half duplex. If par. 12-12 is set to: ON, this parameter is
read only.
[0] Half duplex
[1] * Full duplex
3.13.3 12-2* Process Data
12-20 Control Instance
Range: Function:
[None, 20, 21, 100, 101, 103] Read only. Displays the originator-to-target connection point. If no CIP connection is present “None”
is displayed.
3 Parameter descriptions FC 300 Programming Guide
170 MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
3
