Danfoss VLT AutomationDrive FC 300 Programming Guide

[41] Reset Trip Reset Trip [41] A reset is issued
[42] Auto-reset Trip
Auto-reset Trip [42] An Auto reset is performed.
[43] Ok key
OK key [43] The Ok key is pressed.
[44] Reset key
Reset key [44] The reset key is pressed.
[45] Left key
Left key [45] The left key is pressed.
[46] Right key
Right key [46] The right key is pressed.
[47] Up key
Up key [47] The up key is pressed.
[48] Down key
Down key [48] The down key is pressed.
[50] Comparator 4
Comparator 4 [50] Use the result of comparator 4.
[51] Comparator 5
Comparator 5 [51] Use the result of comparator 5.
[60] Logic rule 4
Logic rule 4 [60] Use the result of logic rule 4.
[61] Logic rule 5
Logic rule 5 [61] Use the result of logic rule 5.
13-02 Stop Event
Select the boolean (TRUE or FALSE) input to activate Smart Logic Control.
Option: Function:
[0] * False For descriptions [0] - [61], see par. 13-01 Start Event Start Event
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
3 Parameter descriptions FC 300 Programming Guide
178 MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
