[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
SL Time-out 3 [70] Smart Logic Controller timer 3 is timed out.
[71] SL Time-out 4
SL Time-out 4 [71] Smart Logic Controller timer 4 is timed out.
[72] SL Time-out 5
SL Time-out 5 [72] Smart Logic Controller timer 5 is timed out.
[73] SL Time-out 6
SL- Time-out 6 [73] Smart Logic Controller timer 6 is timed out.
[74] SL Time-out 7
SL Time-out 7 [74] Smart Logic Controller timer 7 is timed out.
[75] Start command given
[76] Digital input x30 2
[77] Digital input x30 3
[78] Digital input x30 4
[79] Digital input x46 1
[80] Digital input x46 3
[81] Digital input x46 5
[82] Digital input x46 7
[83] Digital input x46 9
[84] Digital input x46 11
[85] Digital input x46 13
13-03 Reset SLC
Option: Function:
[0] * Do not reset SLC Retains programmed settings in all group 13 parameters (13-*).
[1] Reset SLC Resets all group 13 parameters (13-*) to default settings.
