Danfoss VLT AutomationDrive FC 300 Programming Guide

13-41 Logic Rule Operator 1
Array [6]
Option: Function:
Select the first logical operator to use on the Boolean inputs from par. 13-40 Logic Rule Boolean 1
and par. 13-42 Logic Rule Boolean 2 .
[13 -XX] signifies the boolean input of par. group 13-*.
[0] * DISABLED Ignores par. 13-42
Logic Rule Boolean 2 , par. 13-43 Logic Rule Operator 2 , and par. 13-44 Logic
Rule Boolean 3
.
[1] AND Evaluates the expression [13-40] AND [13-42].
[2] OR evaluates the expression [13-40] OR[13-42].
[3] AND NOT evaluates the expression [13-40] AND NOT [13-42].
[4] OR NOT evaluates the expression [13-40] OR NOT [13-42].
[5] NOT AND evaluates the expression NOT [13-40] AND [13-42].
[6] NOT OR evaluates the expression NOT [13-40] OR [13-42].
[7] NOT AND NOT evaluates the expression NOT [13-40] AND NOT [13-42].
[8] NOT OR NOT evaluates the expression NOT [13-40] OR NOT [13-42].
13-42 Logic Rule Boolean 2
Array [6]
Option: Function:
[0] * False Select the second boolean (TRUE or FALSE) input for the selected logic rule. See par. 13-01 Start
Event
([0] - [61]) and par. 13-02 Stop Event ([70] - [75]) for further description.
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
3 Parameter descriptions FC 300 Programming Guide
186 MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
3
