Danfoss VLT AutomationDrive FC 300 Programming Guide

Digtal input Decimal value. See par. 16-60 Digital Input for description
after converting to binary value.
Digital output (not monitored in
this SW release)
Decimal value. See par. 16-66 Digital Output [bin] for de-
scription after converting to binary value.
Warning word Decimal value. See par. 16-92
Warning Word for descrip-
tion.
Alarm word Decimal value. See par. 16-90 Alarm Word for description.
Status word Decimal value. See par. 16-03
Status Word for description
after converting to binary value.
Control word Decimal value. See par. 16-00 Control Word for description.
Extended status word Decimal value. See par. 16-94
Ext. Status Word for de-
scription.
15-22 Historic Log: Time
Array [50]
Range: Function:
0 ms* [0 - 2147483647 ms] View the time at which the logged event occurred. Time is measured in ms since frequency converter
start. The max. value corresponds to approx. 24 days which means that the count will restart at
zero after this time period.
3.16.5 15-3* Alarm Log
Parameters in this group are array parameters, where up to 10 fault logs can be viewed. [0] is the most recent logged data, and [9] the oldest. Error
codes, values, and time stamp can be viewed for all logged data.
15-30 Fault Log: Error Code
Array [10]
Range: Function:
0* [0 - 255 ] View the error code and look up its meaning in the Troubleshooting chapter of the FC 300 Design
Guide.
15-31 Alarm Log: Value
Array [10]
Range: Function:
0 N/A* [-32767 - 32767 N/A] View an extra description of the error. This parameter is mostly used in combination with alarm 38
‘internal fault’.
15-32 Alarm Log: Time
Array [10]
Range: Function:
0 s* [0 - 2147483647 s] View the time when the logged event occurred. Time is measured in seconds from frequency con-
verter start-up.
3.16.6 15-4* Drive Identification
Parameters containing read only information about the hardware and software configuration of the frequency converter.
15-40 FC Type
Range: Function:
0* [0 - 0 ] View the FC type. The read-out is identical to the FC 300 Series power field of the type code defi-
nition, characters 1-6.
FC 300 Programming Guide 3 Parameter descriptions
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark 209
3
