Danfoss VLT AutomationDrive FC 300 Programming Guide

16-79 Analog Out X45/3 [mA]
Range: Function:
0.000* [0.000 - 30.000 ] View the actual value at output X45/3. The value shown reflects the selection in par. 6-80 Terminal
X45/3 Output
.
3.17.7 16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control words.
16-80 Fieldbus CTW 1
Range: Function:
0 N/A* [0 - 65535 N/A] View the two-byte Control word (CTW) received from the Bus-Master. Interpretation of the Control
word depends on the fieldbus option installed and the Control word profile selected in
par. 8-10
Control Profile .
For more information please refer to the relevant fieldbus manual.
16-82 Fieldbus REF 1
Range: Function:
0 N/A* [-200 - 200 N/A] View the two-byte word sent with the control word form the Bus-Master to set the reference value.
For more information please refer to the relevant fieldbus manual.
16-84 Comm. Option STW
Range: Function:
0 N/A* [0 - 65535 N/A] View the extended fieldbus comm. option status word.
For more information please refer to the relevant fieldbus manual.
16-85 FC Port CTW 1
Range: Function:
0 N/A* [0 - 65535 N/A] View the two-byte Control word (CTW) received from the Bus-Master. Interpretation of the control
word depends on the fieldbus option installed and the Control word profile selected in
par. 8-10
Control Profile .
16-86 FC Port REF 1
Range: Function:
0 N/A* [-200 - 200 N/A] View the two-byte Status word (STW) sent to the Bus-Master. Interpretation of the Status word
depends on the fieldbus option installed and the Control word profile selected in par. 8-10
Control
Profile
.
3.17.8 16-9* Diagnosis Read-Outs
Parameters displaying alarm, warning and extended status words.
16-90 Alarm Word
Range: Function:
0 N/A* [0 - 4294967295 N/A] View the alarm word sent via the serial communication port in hex code.
16-91 Alarm Word 2
Range: Function:
0* [0 - 4294967295 ] View the alarm word sent via the serial communication port in hex code.
FC 300 Programming Guide 3 Parameter descriptions
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark 219
3
