35-06 Temperature Sensor Alarm Function
Select the alarm function:
Option: Function:
[0] Off
[2] Stop
[5] * Stop and trip
3.21.2 35-1* Temp. Input X48/4 (MCB 114)
35-14 Term. X48/4 Filter Time Constant
Range: Function:
0.001 s* [0.001 - 10.000 s] Enter the filter time constant. This is a first-order digital low pass filter time constant for suppressing
electrical noise in terminal X48/4. A high time constant value improves dampening but also increases
the time delay through the filter.
35-15 Term. X48/4 Temp. Monitor
This parameter gives the possibility of enabling or disabling the temperature monitor for terminal X48/4. The temperature limits can be set in par.
35-16 and par. 35-17.
Option: Function:
[0] * Disabled
[1] Enabled
35-16 Term. X48/4 Low Temp. Limit
Range: Function:
Application
dependent*
[Application dependant] Enter the minimum temperature reading that is expected for normal operation of the temperature
sensor at terminal X48/4.
35-17 Term. X48/4 High Temp. Limit
Range: Function:
Application
dependent*
[Application dependant] Enter the maximum temperature reading that is expected for normal operation of the temperature
sensor at terminal X48/4.
3.21.3 35-2* Temp. Input X48/7 (MCB 114)
35-24 Term. X48/7 Filter Time Constant
Range: Function:
0.001 s* [0.001 - 10.000 s] Enter the filter time constant. This is a first-order digital low pass filter time constant for suppressing
electrical noise in terminal X48/7. A high time constant value improves dampening but also increases
the time delay through the filter.
35-25 Term. X48/7 Temp. Monitor
This parameter gives the possibility of enabling or disabling the temperature monitor for terminal X48/7. The temperature limits can be set in par.
35-26 and 35-27.
Option: Function:
[0] * Disabled
[1] Enabled
3 Parameter descriptions FC 300 Programming Guide
230
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
3
