35-26 Term. X48/7 Low Temp. Limit
Range: Function:
Application
dependent*
[Application dependant] Enter the minimum temperature reading that is expected for normal operation of the temperature
sensor at terminal X48/7.
35-27 Term. X48/7 High Temp. Limit
Range: Function:
Application
dependent*
[Application dependant] Enter the maximum temperature reading that is expected for normal operation of the temperature
sensor at terminal X48/7.
3.21.4 35-3* Temp. Input X48/10 (MCB 114)
35-34 Term. X48/10 Filter Time Constant
Range: Function:
0.001 s* [0.001 - 10.000 s] Enter the filter time constant. This is a first-order digital low pass filter time constant for suppressing
electrical noise in terminal X48/10. A high time constant value improves dampening but also in-
creases the time delay through the filter.
35-35 Term. X48/10 Temp. Monitor
This parameter gives the possibility of enabling or disabling the temperature monitor for terminal X48/10. The temperature limits can be set in pars.
35-36/37.
Option: Function:
[0] * Disabled
[1] Enabled
35-36 Term. X48/10 Low Temp. Limit
Range: Function:
Application
dependent*
[Application dependant] Enter the minimum temperature reading that is expected for normal operation of the temperature
sensor at terminal X48/10.
35-37 Term. X48/10 High Temp. Limit
Range: Function:
Application
dependent*
[Application dependant] Enter the maximum temperature reading that is expected for normal operation of the temperature
sensor at terminal X48/10.
3.21.5 35-4* Analog Input X48/2 (MCB 114)
35-42 Term. X48/2 Low Current
Range: Function:
4.00 mA* [Application dependant] Enter the current (mA) that corresponds to the low reference value, set in par. 35-44. The value
must be set at > 2 mA in order to activate the Live Zero Time-out Function in par. 6-01.
35-43 Term. X48/2 High Current
Range: Function:
20.00 mA* [Application dependant] Enter the current (mA) that corresponds to the high reference value (set in par. 35-45).
35-44 Term. X48/2 Low Ref./Feedb. Value
Range: Function:
0.000* [-999999.999 - 999999.999 ] Enter the reference or feedback value (in RPM, Hz, bar, etc.) that corresponds to the voltage or
current set in par. 35-42.
FC 300 Programming Guide 3 Parameter descriptions
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
231
3
