Danfoss VLT AutomationDrive FC 300 - Page 274

Ssi Data Length 17-24 221
Stall Protection 14-35 201
Start Current 1-76 58
Start Delay 56
Start Delay 1-71 56
Start Event 13-01 176
Start Function 56
Start Function 1-72 56
Start Select 8-53 147
[Start Speed Hz] 1-75 57
[Start Speed Rpm] 1-74 57
Start/stop 13
Stator Leakage Reactance 49
Stator Leakage Reactance (x1) 1-33 50
Stator Resistance (rs) 1-30 50
Status 16
Status Messages 15
Status Word 16-03 212
Status Word 1 9-68 159
Step Size 3-90 84
Step-by-step 24
Stop Delay 2-24 69
Stop Event 13-02 178
Store Always 10-33 168
Store Data Values 10-31 168
Sw Id Control Card 15-49 210
Sw Id Power Card 15-50 210
Switching Frequency 14-01 194
Switching Pattern 14-00 194
Synchronous Motor Speed 5
T
Telegram Selection 8-40 140
Telegram Selection 9-22 153
Temp. Input X48/10 18-39 224
Temp. Input X48/4 18-37 224
Temp. Input X48/7 18-38 224
Temperature Sensor Alarm Function 35-06 230
Term 32/33 Encoder Direction 5-71 114
Term 32/33 Pulses Per Revolution 5-70 113
Term X30/6 Digi Out (mcb 101) 5-32 102
Term X30/7 Digi Out (mcb 101) 5-33 103
Term. 29 High Frequency 5-51 109
Term. 29 High Ref./feedb. Value 5-53 110
Term. 29 Low Frequency 5-50 109
Term. 29 Low Ref./feedb. Value 5-52 109
Term. 33 High Frequency 5-56 110
Term. 33 High Ref./feedb. Value 5-58 110
Term. 33 Low Frequency 5-55 110
Term. 33 Low Ref./feedb. Value 5-57 110
Term. X30/11 Filter Time Constant 6-36 119
Term. X30/11 High Ref./feedb. Value 6-35 119
Term. X30/11 Low Ref./feedb. Value 6-34 119
Term. X30/12 Filter Time Constant 6-46 120
Term. X30/12 High Ref./feedb. Value 6-45 119
Term. X30/12 Low Ref./feedb. Value 6-44 119
Term. X48/10 Filter Time Constant 35-34 231
Term. X48/10 High Temp. Limit 35-37 231
Term. X48/10 Input Type 35-05 229
Term. X48/10 Low Temp. Limit 35-36 231
Term. X48/10 Temp. Monitor 35-35 231
Term. X48/10 Temp. Unit 35-04 229
Term. X48/2 Filter Time Constant 35-46 232
Term. X48/2 High Current 35-43 231
Term. X48/2 High Ref./feedb. Value 35-45 232
Term. X48/2 Low Current 35-42 231
Term. X48/2 Low Ref./feedb. Value 35-44 231
FC 300 Programming Guide Index
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark 273
