Danfoss VLT AutomationDrive FC 301 Programming Guide

Parameter 3-15 Reference Resource 1
Table 199: Parameter 3-15 Reference Resource 1
3-15 Reference Resource 1
Default value: [1] Analog input 53
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Select the reference input to be used for the 1
st
reference signal. Parameter 3-15 Resource Reference 1, parameter 3-16 Resource Refer-
ence 2, and parameter 3-17 Resource Reference 3 define up to 3 different reference signals. The sum of these reference signals defines
the actual reference. Select the speed reference source in parameter 3-15 Reference Resource 1 when parameter 1-00 Configuration
Mode is set to [9] Positioning in positioning mode.
N O T I C E
The options [3],[4],[5], [6], [12], [13], and [14] are only available with software version 48.XX.
Option
Name
Description
[0]
No function
[1]*
Analog Input 53
[2]
Analog Input 54
[3]
24V Encoder 32/33
[4]
MCB 102
[5]
MCB 103
[6]
Virtual Master
[7]
Frequency Input 29
N O T I C E
This option is only available in FC 302.
[8]
Frequency Input 33
[11]
Local Bus Reference
Reference from terminals 68 and 69.
[12]
Preset Reference
Select this option to set the speed reference in parameter 3-10 Preset Reference together with
the preset target in parameter 3-20 Preset Target to calculate speed profile for positioning.
[13]
24V Encoder 27/29
[14]
MCB 102 Absolute
[15]
MCO Encoder 1 X56
[16]
MCO Encoder 2 X55
[20]
Digital Potmeter
[21]
Analog Input X30/11
VLT® General Purpose I/O MCB 101
[22]
Analog Input X30/12
VLT® General Purpose I/O MCB 101
[29]
Analog Input X48/2
AU275636650261en-000101 / 130R0334 | 131Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
