Option
Name
Description
Target position is reached in touch probe position mode.
[227]
Touch activated
Touch probe positioning is active. The drive monitors the touch probe sensor input.
[228]
Comparator 6
[229]
Comparator 7
[230]
Comparator 8
[231]
Comparator 9
[232]
Logic rule 6
[233]
Logic rule 7
[234]
Logic rule 8
[235]
Logic rule 9
[236]
SL time-out 8
[237]
SL time-out 9
[238]
RS flipflop 8
[239]
RS flipflop 9
[240]
SL digital output A
[241]
SL digital output B
[242]
SL digital output C
[243]
SL digital output D
[244]
SL digital output E
[245]
SL digital output F
Parameter 13-41 Logic Rule Operator 1
Table 682: Parameter 13-41 Logic Rule Operator 1
13-41 Logic Rule Operator 1
Default value: Size related
Parameter type: Option, Array [10]
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
Select the 1
st
logical operator to use on the boolean inputs from parameter 13-40 Logic Rule Boolean 1 and parameter 13-42 Logic
Rule Boolean 2. Parameter numbers in square brackets stand for the boolean inputs of parameters in parameter group 13-** Smart
Logic Control.
Option
Name
Description
[0]
DISABLED
Ignores
Parameter 13-42 Logic Rule Boolean 2.
Parameter 13-43 Logic Rule Operator 2.
Parameter 13-44 Logic Rule Boolean 3.
[1]
AND
Evaluates the expression [13-40] AND [13-42].
AU275636650261en-000101 / 130R0334 | 403Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
