Danfoss VLT AutomationDrive FC 301 Programming Guide

Option
Name
Description
[2]
OR
Evaluates the expression [13-40] OR [13-42].
[3]
AND NOT
Evaluates the expression [13-40] AND NOT [13-42].
[4]
OR NOT
Evaluates the expression [13-40] OR NOT [13-42].
[5]
NOT AND
Evaluates the expression NOT [13-40] AND [13-42].
[6]
NOT OR
Evaluates the expression NOT [13-40] OR [13-42].
[7]
NOT AND NOT
Evaluates the expression NOT [13-40] AND NOT [13-42].
[8]
NOT OR NOT
Evaluates the expression NOT [13-40] OR NOT [13-42].
Parameter 13-42: Logic Rule Boolean 2
Table 683: Parameter 13-42 Logic Rule Boolean 2
13-42 Logic Rule Boolean 2
Default value: Size related
Parameter type: Option, Array [10]
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]
False
Select the 2
nd
boolean (true or false) input for the selected logic rule. See parameter 13-01
Start Event and parameter 13-02 Stop Event for more information.
[1]
True
[2]
Running
[3]
In range
[4]
On reference
[5]
Torque limit
[6]
Current limit
[7]
Out of current range
[8]
Below I low
[9]
Above I high
[10]
Out of speed range
[11]
Below speed low
[12]
Above speed high
[13]
Out of feedb. range
[14]
Below feedb. low
[15]
Above feedb. high
[16]
Thermal warning
[17]
Mains out of range
[18]
Reversing
AU275636650261en-000101 / 130R0334404 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
