View the setting of terminal 54.
Option
Name
Description
[0]*
Current
[1]
Voltage
Parameter 16-64 Analog Input 54
Table 878: Parameter 16-64 Analog Input 54
16-64 Analog Input 54
Default value: 0
Parameter type: Range, -20 - 20
Setup: All setups
Conversion index: -3
Data type: Int32
Change during operation: False
View the actual value at input 54.
Parameter 16-65 Analog Output 42 [mA]
Table 879: Parameter 16-65 Analog Output 42 [mA]
16-65 Analog Output 42 [mA]
Default value: 0
Parameter type: Range, 0 - 30
Setup: All setups
Conversion index: -3
Data type: Int16
Change during operation: False
View the actual value at output 42 in mA. The value shown reflects the selection in parameter 6-50 Terminal 42 Output.
Parameter 16-66 Digital Output [bin]
Table 880: Parameter 16-66 Digital Output [bin]
16-66 Digital Output [bin]
Default value: 0
Parameter type: Range, 0 - 15
Setup: All setups
Conversion index: 0
Data type: Int16
Change during operation: False
View the binary value of all digital outputs.
Parameter 16-67 Freq. Input #29 [Hz]
Table 881: Parameter 16-67 Freq. Input #29 [Hz]
16-67 Freq. Input #29 [Hz]
Default value: 0
Parameter type: Range, 0 - 130000
Setup: All setups
Conversion index: 0
Data type: Int32
Change during operation: False
View the actual frequency rate on terminal 29.
Parameter 16-68 Freq. Input #33 [Hz]
Table 882: Parameter 16-68 Freq. Input #33 [Hz]
16-68 Freq. Input #33 [Hz]
Default value: 0
Parameter type: Range, 0 - 130000
Setup: All setups
Conversion index: 0
Data type: Int32
Change during operation: False
View the actual value of the frequency applied at terminal 33 as an impulse input.
AU275636650261en-000101 / 130R0334 | 509Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
