Danfoss VLT AutomationDrive FC 301 Programming Guide

Parameter 16-69 Pulse Output #27 [Hz]
Table 883: Parameter 16-69 Pulse Output #27 [Hz]
16-69 Pulse Output #27 [Hz]
Default value: 0
Parameter type: Range, 0 - 40000
Setup: All setups
Conversion index: 0
Data type: Int32
Change during operation: False
View the actual value of pulses applied to terminal 27 in digital output mode.
Parameter 16-70 Pulse Output #29 [Hz]
Table 884: Parameter 16-70 Pulse Output #29 [Hz]
16-70 Pulse Output #29 [Hz]
Default value: 0
Parameter type: Range, 0 - 40000
Setup: All setups
Conversion index: 0
Data type: Int32
Change during operation: False
View the actual value of pulses at terminal 29 in digital output mode.
Parameter 16-71 Relay Output [bin]
Table 885: Parameter 16-71 Relay Output [bin]
16-71 Relay Output [bin]
Default value: 0
Parameter type: Range, 0 - 511
Setup: All setups
Conversion index: 0
Data type: Int16
Change during operation: False
View the settings of all relays.
R eadout choic e (P16-71):
R ela y output (bin):
OptionB car d r ela y 08
OptionB car d r ela y 07
P o w er car d r ela y 02
P o w er car d r ela y 01
OptionB car d r ela y 09
e30ba195.11
00000 bin
Illustration 93: Relay Settings
Parameter 16-72 Counter A
Table 886: Parameter 16-72 Counter A
16-72 Counter A
Default value: 0
Parameter type: Range, -2147483648 - 2147483647
Setup: All setups
Conversion index: 0
Data type: Int32
Change during operation: True
View the present value of counter A. Counters are useful as comparator operands, see parameter 13-10 Comparator Operand. Reset
or change the value either via digital inputs (parameter group 5-1* Digital Inputs) or by using an SLC action (parameter 13-52 SL Con-
troller Action).
Parameter 16-73 Counter B
Table 887: Parameter 16-73 Counter B
16-73 Counter B
Default value: 0
Parameter type: Range, -2147483648 - 2147483647
Setup: All setups
Conversion index: 0
Data type: Int32
Change during operation: True
AU275636650261en-000101 / 130R0334510 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
