2
1
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
130BD647.10
1 J7 frequency converter 10 I/O cable clamps
2 Removable fan assembly 11 Terminal cover
3 M5 screw X4 (for fan assembly) 12 Motor terminals
4 NLCP (accessory) 13 Load sharing terminals
5 B options (MCB 102/MCB 103 accessories) 14 Removable plugger (for load sharing terminal)
6 I/O terminals 15 Shielded cable grounding clamps
7 I/O terminals 16 Mains terminals
8 Pluggable RS485 terminals 17 Decoupling plate (accessory)
9 Relay terminal 1&2, xed 18 M4 screw X3 (for decoupling plate)
Illustration 1.3 Exploded View, J6–J7 (30–75 kW/40–100 hp), IP20 (Taking J7 as an example)
Introduction Quick Guide
MG06A702 Danfoss A/S © 03/2017 All rights reserved. 7
