Danfoss VLT FC 100 Series Programming Guide

5-63 Terminal 29 Pulse Output Variable
Option: Function:
[0] *
No operation Select the variable for viewing on the terminal 29 display.
This parameter cannot be adjusted while the motor is running.
5-65 Pulse Output Maximum Frequency #29
Option: Function:
[5000Hz] *
0 - 32000 Hz Set the maximum frequency for terminal 29 corresponding to the output variable set in par. 5-63.
This parameter cannot be adjusted while the motor is running.
5-66 Terminal X30/6 Pulse Output Variable
Option: Function:
[0] *
No operation Select the variable for read-out on terminal X30/6.
This parameter cannot be adjusted while the motor is running.
This parameter is active when option module MCB 101 is installed in the frequency converter.
5-68 Pulse Output Maximum Frequency #X30/6
Range: Function:
5000Hz * [0 - 32000 Hz]
Select the maximum frequency on terminal X30/6 referring to the output variable in par. 5-66. This parameter
cannot be adjusted while the motor is running.
This parameter is active when option module MCB 101 is mounted in the frequency converter.
3.7.9. 5-9*Bus Controlled
This parameter group selects digital and relay outputs via a fieldbus setting.
5-90 Digital & Relay Bus Control
Range: Function:
[0 - FFFFFFFF] This parameter holds the state of the digital outputs and relays that is controlled by bus.
A logical '1' indicates that the output is high or active.
A logical '0' indicates that the output is low or inactive.
Bit 0
CC Digital Output Terminal 27
Bit 1 CC Digital Output Terminal 29
Bit 2 GPIO Digital Output Terminal X 30/6
Bit 3 GPIO Digital Output Terminal X 30/7
Bit 4 CC Relay 1 output terminal
Bit 5 CC Relay 2 output terminal
Bit 6 Option B Relay 1 output terminal
Bit 7 Option B Relay 2 output terminal
Bit 8 Option B Relay 3 output terminal
Bit 9-15 Reserved for future terminals
Bit 16 Option C Relay 1 output terminal
Bit 17 Option C Relay 2 output terminal
Bit 18 Option C Relay 3 output terminal
Bit 19 Option C Relay 4 output terminal
Bit 20 Option C Relay 5 output terminal
Bit 21 Option C Relay 6 output terminal
Bit 22 Option C Relay 7 output terminal
Bit 23 Option C Relay 8 output terminal
Bit 24-31 Reserved for future terminals
5-93 Pulse Out #27 Bus Control
Range: Function:
160 % * [1 - 1000 %]
Contains the frequency to apply to the digital output terminal 27, when it is configured as [Bus Controlled].
3. Parameter Description VLT
®
HVAC Drive Programming Guide
78 MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
3
